Horizontal Hammer Mill Shredder
Input Size : Customize
Output Capacity : 500-30000kg/h
Applicable Material : Car body with engine, Bike scrap, Light metal (≤6mm), Square steel, Channel steel, Home appliance, Color steel title.
Product Description
The Horizontal Hammer Mill Shredder for the metal scrap is for different kind of metal ,car body with engine，bike scrap,square steel , aluminum can , copper plate , painting bucket, tinplate , auto bike scrap etc could be fed into the metal hammer mill .
Metal waste hammer mill is used the hammer hitting principle under high speed and motor torque,when raw material feeds into the working chamber under continue hitting by the hammer ,the right and suitable material between the hammer and liar will be discharged from mesh.
Applicable Hammer Mill For Metal Shredder:
√ Car body with engine
√ Bike scrap
√ Light metal (≤6mm)
√ Square steel
√ Channel steel
√ Home appliance
√ Color steel title
Hammer Mill For Metal Shredder
For the inconvenient crush material , there are assembled the discharge door to protect the machine , once the impossible raw material feeds into the machine it will jump and outcome from the discharge part by automatic .
The whole system is the full automatic after hammer mill , if for the ferrous metal separating the eddy current separator will be assembled with the whole system. Meanwhile to avoid pollution the filter bag dust catcher has been assembled with the line to satisfy environment standard.
FINAL PRODUCT
Technical Parameters
| Model | Voltage | Power(kw) | Production capacity (t/h) | Configure auxiliary machine |
| PSJ-140 | 380V | 132 | 2-3 | 1 feeding conveyor
1 discharge conveyor 1 iron conveyor 1 impurity conveyor 1 magnetic separation system 1 dust removal system Intelligent visualization system (optional 1 set) Set of spray system (optional 1 set) |
| PSJ-200 | 380V | 200 | 3-5 | |
| PSJ-280 | 380V | 280 | 4-7 | |
| PSJ-315 | 380V | 315 | 5-8 | |
| PSJ-450 | 380V/10KV | 450 | 8-12 | |
| PSJ-630 | 10KV | 630 | 10-15 | |
| PSJ-750 | 10KV | 750 | 12-17 | |
| PSJ-800 | 10KV | 800 | 15-20 | |
| PSJ-900 | 10KV | 900 | 20-30 | |
| 1500horsepower | 10KV | 1200 | 25-40 | |
| 2000horsepower | 10KV | 1500 | 50-60 | |
| 3000horsepower | 10KV | 2250 | 60-80 | |
| 4000horsepower | 10KV | 3000 | 80-100 | |
| 6000horsepower | 10KV | 4420 | 100-160 | |
| 8000horsepower | 10KV | 6000 | 160-200 | |
| 10000horsepower | 10KV | 7500 | 200-260 |
