Waste Manual Sorting Platform

The operators responsibility is to sort the different kinds material to the tank . mainly to sort the water bottle , drinks cans , glass ,rubber ,paper etc to the tank .

The garbage manual sorting platform material is made of the under;

feeding port takes agnle steel, the side board takes Q235A , beam takes hot- rolled H steel ,rib distributor takes hot -rolled channel steel etc Both sides of the soring platform setted urgent button

FEATURES

The operators responsibility is to sort the different kinds material to the tank . mainly to sort the water bottle , drinks cans , glass ,rubber ,paper etc to the tank .

The garbage manual sorting platform material is made of the under; feeding port takes agnle steel, the side board takes Q235A , beam takes hot- rolled H steel ,rib distributor takes hot -rolled channel steel etc

Both sides of the soring platform setted urgent button

Waste Sorting & Recycling Line

We can design the most suitable waste sorting recycling process according to your materials for free.

Working Process of Waste Sorting Plant

TECHNICAL PARAMETERS

Model XRD-B800 XRD-B1200
Conveyor Weight material conveyor Light material conveyor
Dimension(mm) 800×10000 Dimension(mm) 1200×10000
Power 4kw Power 7.5kw
Sorting platform Four-person sorting satation Ten-person sorting satation
Dimension(mm) 800×8000 Dimension(mm) 1200×13000
Power 4kw Power 7.5kw
Sorting conveyor Dimension(mm) 800×8000 Dimension(mm) 1200×13000
Working platform dimension 7000×1000×1000mm 12000×1000×1000mm
Bottomless trash can 4 10
Removable trash can 2 5
