Waste Winnowing Machine

appliance : Urban waste , construction trash , decoration scrap

waste winnowing machine is sorted into three kinds: postive winnowing ,negative winnowing , and postive and negative combined . it consists of centrifugal blower,rotary drum, conveyor etc. the light material will be segretated from heavy material under controlled postive and negeitve winnowing. The light will up or balance move to storage chamber , which discharged by the conveyor , the heavy material keeps on the conveyor for the air can not lift or move it .

FEATURES

Appliance : Urban waste , construction trash , decoration scrap

Waste winnowing machine is sorted into three kinds: postive winnowing ,negative winnowing , and postive and negative combined . it consists of centrifugal blower,rotary drum, conveyor etc. the light material will be segretated from heavy material under controlled postive and negeitve winnowing. The light will up or balance move to storage chamber , which discharged by the conveyor , the heavy material keeps on the conveyor for the air can not lift or move it .

Results

the light material: weaving bags , paper , plastic shopping bags etc

The heavy material: higher density and gravity material

Character

1.Negative sorting method is no dust leakge

2.stepless of blower to meet different character material including high moisture meterial

3. there is no need to set winnowing system or filter system (excluding specail required)

4. Double drums sorting system to sort light .middle , and heavy material

5.lower spare part cost and faults

6.Modular type saves maintenance time

TECHNICAL PARAMETERS

Model Capacity (t/h) Power (kw) The Details  of Power (kw)
XRD-A600 20 26.7 7.5+5.5+5.5+3+3+2.2
XRD-A800 40 37 11+7.5+7.5+4+4+3
XRD-A1000 60 44 15+7.5+7.5++5.5+5.5+3
XRD-A1200 80 55.5 18.5+11+11+5.5+5.5+4
XRD-A1400 100 59 22+11+11+5.5+5.5+4
XRD-A1600 120 79 30+15+15+7.5+7.5+4
